Vibration Tester AVD-80




Vibration Tester AVD -80 Micro Controller Based has been designed as simple diagnostic tool for preventive maintenance. The instrument and the monitoring technique are based on the recommendations of ISO standard. Need based maintenance is the latest trend of industry with which maintenance costs are low and life machinery is most optimum. Condition monitoring is basic need for need maintenance.

All three useful measurements are possible. Suitable for monitoring machinery vibration caused by imbalance, misalignment and gear faults. Displacement, Velocity and acceleration modes allow a user to perform basic vibration analysis

Features



  • Measuring Vibration: Displacement , Acceleration and Velocity
  • True  RMS measurement &Peak-Peak
  • Sealed  Membrane key pad
  • Micro Controller based
  • Back Light Display
  • Auto Off
  • Battery Low Indication
  • Pocket size and Light weight


Technical Data :



  • Displacement Measuring Range:0.5 -1000 m True RMS, 0.5 - 2828 PK - PK
  • Accuracy:(+ 5%)
  • Velocity Measuring Range: 0.1 - 200 mm/sec, 0.1 - 565 mm/s PK - PKTrue RMS
  • Accuracy:+ (2% + 0.1 mm/s)
  • Acceleration Measuring Range:0.1 - 200 m/sec, 0.1 - 565 m/sPK - PKTrue RMS
  • Accuracy: (2% + 0.1 m/s)
  • Resolution:0.1 mm/s
  • Accuracy: + (2% + 0.1 mm/s)
  • Frequency response : 10HZ - 1KHZ
  • Temperature Range : 0 - 55 degree C
  • Power Supply: 9V - 6 F22
  • Display:2 x 8 Dot Matrix LCD Large Characters with back light
  • Auto Off:Yes
  • Battery Low Indication:Yes
  • Weight : 200gms
  • Size : 135x70x25mm




Standard Supply :



  • 1) Vibration Tester AVD-80 with Pouch,
  • 2) Vibration Transducer (Accelerometer) VSF-1F, Magnetic Base,Hand Held Probe Rod, Low Noise Cable with Connectors (1.5 Mtrs)
  • 3) Manual,
  • 4) 9V Battery (Alkaline),
  • 5) Test & Calibration Report with Warranty/Guarantee Certificate
  • 6) Carry Case.
